深圳市百盛新紀元半導體有限公司，自成立以來，始終堅守誠信為本的原則，專注于半導體領域的技術創新與服務提升。我們專注于DC-DC升壓轉換芯片、降壓轉換芯片、MOS場效應管、LDO穩壓芯片、鋰電池充電管理芯片、鋰電池保護系統芯片、過壓過流保護芯片、電壓檢測芯片的研發與銷售，憑借多年的半導體銷售從業經驗和公司經驗豐富的FAE團隊，我們?yōu)榭蛻籼峁﹥?yōu)質的產品和全方位的服務。
我們的產品廣泛應用于智能機器人、無線充、移動電源、無人機、安防監控、車載導航、行車記錄、暖手寶、補水儀、玩具等領域，以卓越的性能和穩定的品質贏得了客戶的廣泛贊譽。無論是產品的性能還是服務的質量，我們都力求做到最好，以滿足客戶不斷變化的需求。
百盛新紀元秉持倉儲式的經營理念，以誠信、感恩、服務為宗旨，致力于為客戶提供多元化、全方位的優質服務。我們深知，只有真正站在客戶的角度思考問題，才能贏得客戶的信賴和支持。因此，我們始終堅持用心服務，用心傾聽，用心滿足客戶的每一個需求。
PL2700智能限流IC，最大2A
詳情
代理PL2700 USB限流開關IC
PL2700，可調限流0.5A-2A，
PL2702，可調限流1A-3A，帶短路保護。 跟PL2700腳位PIN對PIN
The PL2700 is a cost-effective, low voltage,single P-MOSFET load switch,optimized for self-powered and bus-powered Universal Serial Bus (USB) applications. This switch operates with inputs rangingfrom2.4Vto5.5V,makingitideal forboth 3V and 5V s The switch's low RDS(ON), 80mΩ ,meets USB voltage drop requirements. The PL2700 is also protected from thermal overload which limits power dissipation and junction temperatures. Current limit threshold is programmed with a resistor from SET to ground. The quiescent supply current is typically 15μA at switch on state. At switch off state the supply current decreases to less than 1μA.The PL2700 is 5 package.
FEATURES
? Compliant to USBSpecifications
? Integrated 80mΩ Power MOSFET
? Low Supply Current
15μA Typical at Switch On State
1μA Typical at Switch Off State
? Wide InputVoltage Range:2.4V to 5.5V
? Fast Transient Response:<2μs
? Reverse Current Flow Blocking
? ThermalShutdownProtection
? Hot Plug-In Application (Soft-Start)
? Available in a 5-Pin SOT23-5Package
